MAX485 Half Duplex Transciever

15.00 Incl. GST

Description

Description

Product Overivew

MAX485 Half Duplex Transciever

MAX485ESA is a RS485 RS422 Transceiver IC. Its used to enable a device to communicate on RS485 bus. It draws between 120µA and 500µA of supply current when unloaded or fully loaded with disabled drivers.  All parts operate from a single 5V supply. Drivers are short-circuit current limited and are protected against excessive power dissipation by thermal shutdown circuitry that places the driver outputs into a high-impedance state. The receiver input has a fail-safe feature that guarantees a logic-high output if the input is open circuit.

Features of MAX485 Half Duplex Transciever

  • Input Supply Voltage (VCC) : 5V
  • Input Current : ±2 µA
  • Maximum Data Rate : 2.5 Mbps
  • Allows Upto 32 Transceivers on Bus, Half Duplex
  • -7V to +12V Common-Mode Input Voltage Range
  • Make : MAXIM

Download Datasheet

Click here to know more
