LM567C Tone Decoder SOIC8 IC are general purpose tone decoders designed to provide a saturated transistor switch to ground when an input signal is present within the passband. The circuit consists of an I and Q detector driven by a voltage controlled oscillator which determines the center frequency of the decoder. External components are used to independently set center frequency, bandwidth and output delay.
Please note that IC specifications and features may vary based on the specific manufacturer and model. To use the LM567 IC effectively, you should refer to the datasheet provided by the manufacturer for detailed information on pin configurations, operating modes, and recommended operating conditions.
Features of LM567C Tone Decoder SOIC8
- 20 to 1 Frequency Range With an External Resistor
- Logic Compatible Output With 100-mA Current Sinking Capability
- Bandwidth Adjustable From 0 to 14%
- High Rejection of Out of Band Signals and Noise
- Immunity to False Signals
- Highly Stable Center Frequency
- Center Frequency Adjustable from 0.01 Hz to 500 kHz
- Operating Supply Voltage-5V
- Operating Supply Current-12 mA
- Minimum Operating Temperature:-0 C
- Maximum Operating Temperature-+ 70 C
- Mounting Style:SMD/SMT
Applications
- Touch Tone Decoding
- Precision Oscillator
- Frequency Monitoring and Control
- Wide Band FSK Demodulation
- Ultrasonic Controls
- Carrier Current Remote Controls
- Communications Paging Decoders
